Building a Dynamic Navigation Component in AEM using Sling Models and the Resource API

In our previous posts, we explored the basics of the Resource ResourceResolver In AEM, and even used the Resource API to list PDF files from a DAM folder using a simple servlet.

Now, let’s put that knowledge to practical use with a real-world component.

In this blog, we’ll walk through how to build a dynamic navigation component in AEM using Sling Models and the Resource API.

This component will allow authors to select a root page path and dynamically generate a list of child pages with their titles and links — no hardcoding, just clean, flexible logic.

Requirement

We want to build a component where authors can configure a starting path. The component will automatically display the titles and links of all child pages under that path.

If the author sets the root path as /content/my-site/enThe navigation will show all subpages, like

• /content/my-site/en/about
• /content/my-site/en/contact
• /content/my-site/en/products

And it should work dynamically — no hardcoded values.

Implementation

1. Component Dialog

Create a dialog in your component with a path field

<?xml version="1.0" encoding="UTF-8"?>
<jcr:root xmlns:jcr="http://www.jcp.org/jcr/1.0" xmlns:nt="http://www.jcp.org/jcr/nt/1.0" xmlns:granite="http://www.adobe.com/jcr/granite/1.0" xmlns:cq="http://www.day.com/jcr/cq/1.0" xmlns:sling="http://sling.apache.org/jcr/sling/1.0"
    jcr:primaryType="nt:unstructured"
    jcr:title="Dynamic Navigation "
    sling:resourceType="cq/gui/components/authoring/dialog">
    <content
        jcr:primaryType="nt:unstructured"
        sling:resourceType="granite/ui/components/coral/foundation/container">
        <items jcr:primaryType="nt:unstructured">
            <tabs
                jcr:primaryType="nt:unstructured"
                sling:resourceType="granite/ui/components/coral/foundation/tabs"
                maximized="{Boolean}true">
                <items jcr:primaryType="nt:unstructured">
                    <properties
                        jcr:primaryType="nt:unstructured"
                        jcr:title="Properties"
                        sling:resourceType="granite/ui/components/coral/foundation/container"
                        margin="{Boolean}true">
                        <items jcr:primaryType="nt:unstructured">
                            <columns
                                jcr:primaryType="nt:unstructured"
                                sling:resourceType="granite/ui/components/coral/foundation/fixedcolumns"
                                margin="{Boolean}true">
                                <items jcr:primaryType="nt:unstructured">
                                    <column
                                        jcr:primaryType="nt:unstructured"
                                        sling:resourceType="granite/ui/components/coral/foundation/container">
                                        <items jcr:primaryType="nt:unstructured">
                                            <rootPath
                                                jcr:primaryType="nt:unstructured"
                                                sling:resourceType="granite/ui/components/coral/foundation/form/pathfield"
                                                fieldLabel="Navigation Root Path"
                                                name="./rootPath"
                                                rootPath="/content"
                                                required="true"/>
                                        </items>
                                    </column>
                                </items>
                            </columns>
                        </items>
                    </properties>
                </items>
            </tabs>
        </items>
    </content>
</jcr:root>

2. Sling Model interface.

package com.debug.code.core.models;

import java.util.List;

public interface NavigationModel {

    String getRootPath();

    List<NavigationItem> getNavigationItems();

    class NavigationItem {
        private final String title;
        private final String path;

        public NavigationItem(String title, String path) {
            this.title = title;
            this.path = path;
        }

        public String getTitle() {
            return title;
        }

        public String getPath() {
            return path;
        }
    }
}

3. Sling Model Implementation

package com.debug.code.core.models.impl;

import com.day.cq.wcm.api.Page;
import com.day.cq.wcm.api.PageManager;
import com.debug.code.core.models.NavigationModel;
import com.debug.code.core.models.NavigationModel.NavigationItem;
import org.apache.commons.lang3.StringUtils;
import org.apache.sling.api.resource.Resource;
import org.apache.sling.api.resource.ResourceResolver;
import org.apache.sling.models.annotations.DefaultInjectionStrategy;
import org.apache.sling.models.annotations.Model;
import org.apache.sling.models.annotations.injectorspecific.ValueMapValue;

import javax.inject.Inject;
import java.util.ArrayList;
import java.util.Iterator;
import java.util.List;

@Model(
        adaptables = Resource.class,
        adapters = NavigationModel.class,
        defaultInjectionStrategy = DefaultInjectionStrategy.OPTIONAL
)
public class NavigationModelImpl implements NavigationModel {

    @ValueMapValue
    private String rootPath;

    @Inject
    private ResourceResolver resourceResolver;

    @Override
    public String getRootPath() {
        return rootPath;
    }

    @Override
    public List<NavigationItem> getNavigationItems() {
        List<NavigationItem> items = new ArrayList<>();

        if (StringUtils.isNotBlank(rootPath)) {
            PageManager pageManager = resourceResolver.adaptTo(PageManager.class);
            if (pageManager != null) {
                Page rootPage = pageManager.getPage(rootPath);
                if (rootPage != null) {
                    Iterator<Page> childPages = rootPage.listChildren();
                    while (childPages.hasNext()) {
                        Page child = childPages.next();
                        String title = StringUtils.defaultIfBlank(child.getTitle(), child.getName());
                        items.add(new NavigationItem(title, child.getPath()));
                    }
                }
            }
        }

        return items;
    }
}

4. HTL Code

<sly data-sly-use.model="com.debug.code.core.models.NavigationModel">

<p>Root Path: ${model.rootPath}</p>
<p>Items Count: ${model.navigationItems.size}</p>

<ul data-sly-list="${model.navigationItems}">
  <li>
    <a href="${item.path}">${item.title}</a>
  </li>
</ul>
</sly>

How it Works

1. We inject the rootPath from the dialog.
2. We adapt the ResourceResolver to a PageManager
3. We fetch the root page using pageManager.getPage(rootPath).
4. We iterate over its children and get their titles and paths.
5. We return a list of NavigationItem objects, which is rendered in the HTL.

The upcoming blog will explore more of the Content Fragment and Headless Approach in detail.
